NCS20062DMR2G Integrated Circuit Ic Chip Opamp Gp 2 Circuit 8msop

Name: NCS20062DMR2G Integrated Circuit Ic Chip Opamp Gp 2 Circuit 8msop
Brand: original
Price: 1 USD

Brand Name : original

Model Number : NCS20062DMR2G

Certification : original

Place of Origin : original

MOQ : 1

Price : negotiation

Payment Terms : T/T

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Voltage - Supply Span (Min) : 1.8 V

Voltage - Supply Span (Max) : 5.5 V

Operating Temperature : -40°C ~ 125°C (TA)

Mounting Type : Surface Mount

Package / Case : 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)

Supplier Device Package : 8-MSOP

Base Product Number : NCS20062

Current - Supply : 140µA (x2 Channels)

Contact Now

NCS20062DMR2G Integrated Circuit Ic Chip Opamp Gp 2 Circuit 8msop

General Purpose Amplifier 2 Circuit Rail-to-Rail 8-MSOP

Specifications of NCS20062DMR2G

TYPE	DESCRIPTION
Category	Integrated Circuits (ICs)
	Linear
	Amplifiers
	Instrumentation, OP Amps, Buffer Amps
Mfr	onsemi
Series	-
Package	Tape & Reel (TR)
	Cut Tape (CT)
	Digi-Reel®
Product Status	Active
Amplifier Type	General Purpose
Number of Circuits	2
Output Type	Rail-to-Rail
Slew Rate	1.2V/µs
Gain Bandwidth Product	3 MHz
Current - Input Bias	1 pA
Voltage - Input Offset	500 µV
Current - Supply	140µA (x2 Channels)

Voltage - Supply Span (Min)	1.8 V
Voltage - Supply Span (Max)	5.5 V
Operating Temperature	-40°C ~ 125°C (TA)
Mounting Type	Surface Mount
Package / Case	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package	8-MSOP
Base Product Number	NCS20062

Features of NCS20062DMR2G

• Gain−Bandwidth Product: 3 MHz

• Low Supply Current/ Channel: 125 A typ (VS = 1.8 V)

• Low Input Offset Voltage: 4 mV max

• Wide Supply Range: 1.8 V to 5.5 V

• Wide Temperature Range: −40°C to +125°C

• Rail−to−Rail Input and Output

• Unity Gain Stable

• Available in Single, Dual and Quad Packages

• NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements;

AEC−Q100 Qualified and PPAP Capable

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant

Applications of NCS20062DMR2G

• Automotive • Battery Powered/ Portable

• Sensor Signal Conditioning

• Low Voltage Current Sensing

• Filter Circuits • Unity Gain Buffer

Environmental & Export Classifications of NCS20062DMR2G

ATTRIBUTE	DESCRIPTION
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.33.0001
